This new Digital force Gauge by Imada (Japan) can measure both tension and compression with very high accuracy and speed, its responding speed is distinguished and it follows even sudden force change, it includes many convient functions such as display reverce, input/output signal and graph drawing with optional software. It is designed for easy holding. With test stand more accurate measurement is available in the field of quality control and R&D.
It is also available with seprate sensor (model) ZTS series. It is available from 0-2N (200 gf) to 0-1000N(100Kgf) for detailed catalouge you can mail us or call us.

Digital Force Gauge ( Model No. ZTA / ZTS )

FEATURES

1 High sensitivity; 2000Hz

2 Organic EL display; Bright and easy to read

3 Graphical indication; Easy to handle

4 Multi display

5 1000 values memorable

6 High / Low set point

7 Measured data can be saved in USB flash drive ( ZTA only )

8 Displacement I/O (ZTA only )

9 Attachments and a carrying case are included

SPECIFICATIONS

Additional Information:

• Delivery Time: Ready Stock

For precision and repeatable measurement, test stand is necessary in order to keep same test contion. It does not need heavy manual labour when applying large forces, and makes the task of obtaining measurements more efficient. All the force gauges shown with the Test Stand are sold separately. Mechanical Test Stand and Motorised Test stand both are available in stock. Range of Test Stand is from 500N to 1000N Different models are there. For detail catalog you can mail us or you can call us.

Motorized Test Stands (Model No. MX  500N/MX-1000N/MX-5000N)

FEATURES

For precise and repeatable measurements, test stand is necessary in order to keep same test condition. It does not need heavy manual labor when applying large forces, and makes the task of obtaining measurements more efficient.

1 Single / Continuous cycle function

2 Fix speed / adjustable speed mode select

3 Overload stop ( Work with ZT series)*1

4 Force control model ( Work with ZT series )*1

5 Power supply: AC 100 ~ 240 V

6 Safety feature: Upper / Lower limit, Emergency button

SPECIFICATION

Digital Fore Gauges ( Model No. ZTA / ZTS ) High Capacity Model

FEATURES

This is high capacity model digital force gauges available in capacity from 2500N ( 250kgf ) up to 5000N (500kgf). Their high sampling rate (2000Hz) provides accurate results for even quick movement testing. It is easy to handle due to clear and bright organic EL displays and graphical display. For more sophisticated analysis, you can use optional software, providing real-time data transferring ( 2000 data/sec ) to PC and graphing smoothly. ZTA series can input/output displacement when they are combined with test stands having linear scales, which is ideal for force-displacement analysis.

1 Strength test for various materials

( tension test, compression test, shearing test, etc. )

2 Measuring of attraction / repulsion force of solenoid or magnet.

3 Adhesion test of laminated tubes.

SPECIFICATIONS

Additional Information:

• Delivery Time: Ready Stock
• Packaging Details: Plastic Box

Manual Test Stands ( Model No. HV – 1000N )

Manual Test Stand

Vertical stand in manual operation; with a minute revolution of 1.2mm/one complete turn of hand-wheel ensures delicate measurement.

Motorized Test Stands ( Model No. MX2-500N/MX-1000N/MX2-2500N)

FEATURES

1 Jog / Manual /Cycle Mode

2 Speed, Timer, Counter settable on display

3 Overload Prevention ( with ZT series ) *1

4 Force Control ( with ZT series )*1

5 Power : AC 100 to 240 V

6 Safety Guard: Upper / Lower stroke limit, Emergency button,

Front shield.

SPECIFICATION

Additional Information:

• Delivery Time: Ready stock

This PSH model is high capacity model which is extra support body with high load range with best reliablity and accuracy, it has a range to measure high force between 500N (50Kg) to 3000N (300Kgf) this is one of the best in high capacity model.

Mechanical Force Gauges ( Model No. PSH )

FEATURES

Hogh Capacity Standard Model

Extra strong body supports high load range with best reliability.

Covers the measurements of high force between 500N~3000N.

1 Strength test for various materials ( tension test, compression test,

Shearing test, etc.

2 Measuring of attraction / repulsion force of solenoid or magnet.

3 Adhesion test of laminated tubes.

Specification

Manual Test Stands ( Model No. SVL  1000 N )Imada japan

FEATURES

For precise and repeatable measurements, test stand is necessary in order to keep same test condition. It does not need heavy manual labor when applying large forces, and makes the task of obtaining measurements more efficient. In the measurement which small movement is required, exact measurement is attained by handle or lever operation.

Manual Test stand for Compression ( lever )

SVL  1000 N is exclusive for compression measurement. Simple one  lever control makes the measurement efficient.

Additional Information:

• Delivery Time: Ready Stock
• Packaging Details: Box packing

Manual Test Stands ( Model No. SVH – 1000 N )

Manual Test Stand ( handle )

SVH – 1000N is compact manual test stand of handle operation. It is simple and easy operation.

SPECIFICATION

Feature

 You can connect maximum 4 pcs of DST to a PC at the same time, for easier management. (You need a dedicated optional software.)
 Using a supplied software (Force Logger) and USB cable, you can easily transfer data from DST to PC.
 DST-2N/5N/20N/50N has a mechanical stopper for preventing overload.
 You can charge DST from a PC or a mobile battery.
 Battery life lasts 30 hours at maximum when its backlight is off.

You may also like DSV series, with a few additional functions for highly repeatable measurement by hand.
High functional type for handheld-use: DSV seies>>

If you need a wide range of force from low to high, we recommend sensor interchangeable amplifier.
Sensor interchangerble amplifier eZT series>>

Specifications for digital force gauge for handheld use DST series

Additional Information:

• Delivery Time: Ready Stock
• Packaging Details: Plastic Carrying Box

Food Hardness Testing Unit FCA-DSV-50N

– It performs easy compression test for a fixed distance.
– It has high repeatability at budget price.

Food Texture Analyzer, FRTS Series

Food Texture Analyzer digitalize food texture such as firmness, viscosity, elasticity and more, allowing for data management

This texture analyzer includes a wide range of preset measuring conditions.  You only have to select a desired food or standard, and follow the instructions displayed to set measuring conditions.
Also, you can use the preset condition with some change.

Data graphing and Analysis
A supplied software visualizes force transition in a graph.
Force vs Time and Force vs Displacement graphs are available.
It automatically calculates firmness, tackiness, cohesion, elasticity, etc (depending on your selected measuring condition).
You can overlay graphs (up to 5) using graph layering function, which is useful for comparing analysis.

Imada (Japan) Mechanical Force Gauge can accurately measure Tensile and comperessive force without power supply.

FEATURES

1 Power supply Needless

2 Durable and high reliability

3 Force transition is readable

4 Ergonomic design for hand held use

5 Rugged die cast aluminium housing

6 Durable high accuracy with exclusive indicator and special

Spring materials

7 Peak force hold on all models

8 Zero adjustment for tare weight

9 Easy to read dial

10 Included attachments and carrying case

Specification

FS/FB model performs steady precision at most affordable price.

Covers the measurements of low to medium force between 10N-500N.

Additional Information:

• Delivery Time: Ready Stock

Digital Torque Gauges ( Model No. HTG2 )

Torque gauge can measure the force of twist and rotation such as tightening screws, locking doors and opening bottle caps. Numerical quality control, instead of evaluation by sense, is important especially in the case of screws and bottles, which can be tightened without limit. The smoothness of keys and rotary switches gives much influence on easy operation. IMADA torque gauge measures these forces easily and precisely.

Hand Held Torque Gauge

For torque of screws or torsion strength. Various types of sensor tip are available.

Special Use Load Sensors

Foot Brakes Force for Cars, Model : ZTA-PK2--1500N

Special use load sensor for stepping foot brakes for cars. measuring foot break manipulating force by putting the load cell on foot breaks and stepping them together

Additional Information:

• Delivery Time: Ready Stock

Manual Test Stands IMADA japan

For tension / compression test up to 500N. Includes mechanical stopper.
